Canal CPS "U"

CE · Información revisada

Si la tabla no cabe en el área visible, desplázala horizontalmente para consultar todas las columnas.

Canal CPS "U"(CE)
DESCRIPCION	PERALTE		PATIN (MM)		ALMA (MM)	PESO NOMINAL
	PULG.	(MM)	ANCHO	ESPESOR	ALMA (MM)	lb / ft	KG / ML	LARGO MT
	A	A	df	df	tw	lb / ft	KG / ML	12.20	6.10
3" X 4.1 lb	3"	76.2	35.8	7	4	4.1	6.10	74.42	37.21
4" X 5.4 lb	4"	101.6	40.2	8	5	5.4	8.04	98.09	49.04
5" X 6.7 lb	5"	127.0	44.4	6	4	6.7	9.96	121.51	60.76
6" X 8.2 lb	6"	152.4	48.7	9	5	8.2	12.20	148.84	74.42
X 10.5 lb			51.5		8	10.5	15.63	190.69	95.34
X 13.0 lb			55.0		11	13.0	19.36	236.19	118.10
8" X 11.5 lb	8"	203.8	57.4	10	6	11.5	17.11	208.74	104.37
X 13.8 lb			60.0		8	13.8	20.48	249.86	124.93
X 18.8 lb			64.0		12	18.8	27.93	340.75	170.37
10" X 15.3 lb	10"	254.0	66.1	11	6	15.3	22.80	278.16	139.08
X 20.0 lb			69.8		10	20.0	29.80	363.56	181.78
X 25.0 lb			73.3		13	25.0	37.20	453.84	226.92
X 30.0 lb			77.1		17	30.0	44.70	545.34	272.67
12" X 20.7 lb	12"	304.8	74.3	11	7	20.7	30.80	375.76	187.88
X 25.0 lb			77.4		10	25.0	37.20	453.84	226.92
X 30.0 lb			80.6		13	30.0	44.70	545.34	272.67
15" X 33.9 lb	15"	381.0	85.7	11	10	33.9	50.60	617.32	308.66
X 40.0 lb			88.9	11	13	40.0	59.53	726.27	363.13
X 50.0 lb			90.4	12	18	50.0	74.41	907.80	453.90
GRADO A-36 A572°50

Ocho peraltes, diecinueve referencias.
